Product Summary

The SKT10 is a Stud Thyristor. The applications of it are DC motor control, controlled rectifiers, AC controllers, recommended snubber network.

Parametrics

SKT10 general specifications: (1)ITSM: TVJ=25℃,10MS:250A, TVJ=130℃,10MS:210A; (2)VT: TVJ=25℃,IT=30A: max.1.6V; (3)VT(TO):TVJ=130℃:max.1V; (4)rT:TVJ=130℃:max.18mΩ; (5)IDD;IRD:TVJ=130℃,VRD=VRRM,VDD=VDRM:max.4mA; (6)(di/dt)cr:&max.50A/μs; (7)(dv/dt)cr:max.500V/μs; (8)tq:80μs; (9)IH:80mA; (10)IL:150mA; (11)VGT:min.3V; (12)IGT:min.100mA; (13)VGD:max.0.25V; (14)IGD:max.3mA.

Features

SKT10 features: (1)hermetic metal case with glass insulator; (2)threaded stud ISO M5; (3)international standard case.

Diagrams
