Product Summary
The 240UR60D is a Standard Recovery. The applications of the 240UR60D include Diodes Welders, Power supplies, Machine tool controls, High power drives, Medium traction applications, Battery charges, Freewheeling diodes.
Parametrics
240UR60D absolute maximum ratings: (1)Maximum junction operating and storage temperature range: - 40 to 180 ℃; (2)Maximum thermal resistance, junction to case: 0.18 K/W; (3)Maximum thermal resistance, case to heatsink: 0.8 K/W; (4)Maximum allowed mounting torque + 0 - 20 %: 37 (330) N·m; (5)Approximate weight: 250 g; (6)Case style: DO-205AB.
Features
240UR60D features: (1)Diffused diode; (2)Wide current range; (3)High voltage ratings up to 1200 V; (4)High surge current capabilities; (5)Stud cathode and stud anode version; (6)Hermetic metal case; (7)RoHS compliant; (8)Designed and qualified for industrial level.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 240UR60D |
|
DIODE STD RECVRY 600V 240A DO-9 |
Data Sheet |
|
|
||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||
|
240U100D |
|
DIODE STD RECVRY 1000V 240A DO-9 |
Data Sheet |
|
|
||||||
|
240U120D |
|
DIODE STD RECVRY 1200V 240A DO-9 |
Data Sheet |
|
|
||||||
|
240U60D |
|
DIODE STD RECVRY 600V 240A DO-9 |
Data Sheet |
|
|
||||||
|
240U80D |
|
DIODE STD RECVRY 800V 240A DO-9 |
Data Sheet |
|
|
||||||
|
240UR100D |
|
DIODE STD RECVRY 1000V 240A DO-9 |
Data Sheet |
|
|
||||||
|
240UR120D |
|
DIODE STD RECVRY 1200V 240A DO-9 |
Data Sheet |
|
|
||||||
